1.63"

1.63 inch 20pin Colorful Amoled Screen Module RM69032 Drive I2C Compatible for MIPI Interface 320*320 Dots

1.63 inch 20pin Colorful Amoled Screen Module RM69032 Drive I2C Compatible for MIPI Interface 320*320 Dots

1.63 inch 20pin Colorful Amoled Screen Module RM69032 Drive I2C Compatible for MIPI Interface 320*320 Dots

1.63 inch 20pin Colorful Amoled Screen Module RM69032 Drive I2C Compatible for MIPI Interface 320*320 Dots

Display Mode:Amoled
Screen Size:1.63
Driver IC:RM69032
Color Configuration:RGB
Product description: Hicenda Technology Co., Ltd can supply 1.63 inch amoled display, high Quality Hot Sale 1.63 Inch amoled Display MIPI 320*320 pixels,1.63 inch 320*320 amoled display module colorful screen for smartwa
INQUIRY

1. Display Specifications

1) Screen Size: 1.63''
2) Interface Type: MIPI
3) Resolution:320*320

4) Drive IC: RM69032

5) Active Area: 26.04 (H)*26.04(V)

6) Operating Temper:-20~+60℃

7) Display Color (M):16.7M

8)Warranty:12 Months

9)Color Configuration:R, G, B

10)Operating Voltage:2.8V~3.1V

11)Storage Temperature:-30℃~+70℃

12)The number of pin:plug 20pin

PREVIOUS：1.45 inch OLED Amoled screen RM69080 Driver IC module 280*280 resolution MIPI interface NEXT：2.4 inch oled amoled display 240*320 dots MCU/RGB/Serial port interface S6E63D6 Driver I2C amoled screen
