1. Display Specifications
PINo Symbol Description
Pin | Define |
1 |
GND GroundD |
2 |
VCC Power 3.3V |
3 |
SCL Serial clock pin. |
4 |
SDA Serial data input |
5 |
RES LCM Reset pin |
6 |
DC Data/Command Control |
7 |
CS Chip Select |
8 |
BLK Backlight control pin |
